<del id="iuqsi"></del> <del id="iuqsi"></del> <del id="iuqsi"></del> I. Energy Storage System Parameters
? Rated Power: 50kW
? Nominal Capacity: 100kWh
? Battery Voltage: 500V
? Charge/Discharge Rate: ≤0.5C
? Depth of Discharge (DOD): ≤95% (Recommended)
? Cycle Life: >6000 cycles
? Cell Type: Lithium Iron Phosphate (e.g., 3.2V/173Ah, 3.2V/280Ah)
? Energy Storage System Efficiency: ≥90%
II. Charging Facility Parameters
? Output Power: 40kW - 50kW
? Input Voltage: AC380V±15%
? Output Voltage Range: DC200V - 500V
? Output Current Range: 0 - 200A
III. PV Parameters
? Rated Power: 50kW
? Voltage Range: DC300V - 500V
? Current Range: 0 - 300A
